Outdoor Communication Optical Cable

GYXTW

Technical features:

• Number of fiber cores: 2 to 96 cores.

• Low loss, low dispersion.

• Reasonable design and precise control of excess length make the optical cable have excellent mechanical and environmental performance.

• Steel wire armor enhances the cable's resistance to lateral pressure and moisture.

• Small structure, light weight, easy to lay.

•The sheath can be produced from low-smoke halogen-free flame retardant materials (the model is GYXTZW at this time)

Outdoor Communication Optical Cable Performance:

• Suitable for inter-office communication, agricultural telephone, local telephone relay, CATV and computer network transmission systems.

• Minimum allowable bending radius: static 10 times the cable diameter, dynamic 20 times the cable diameter.

• Working temperature: -40～+70℃.

GYXTW53

Technical features:

• Number of fiber cores: 2 to 96 cores.

• Low loss, low dispersion, to ensure excellent optical transmission characteristics of the fiber.

• Reasonable design and precise control of excess length make the optical cable have excellent mechanical and environmental performance.

• Double-layer steel tape armor increases the lateral pressure resistance and anti-bite performance of the optical cable.

Performance:

• Suitable for inter-office communication, agricultural telephone, local telephone relay, CATV and computer network transmission systems.

• Minimum allowable bending radius: static 12.5 times the cable diameter, dynamic 25 times the cable diameter.

• Working temperature: -40～+70℃.

GYFXTF

Technical features:

• Number of fiber cores: 2 to 96 cores.

• Low loss, low dispersion, to ensure excellent optical transmission characteristics of the fiber.

• Reasonable design and precise control of excess length make the optical cable have excellent mechanical and environmental performance.

• Non-metal reinforced FRP reinforced tape greatly reduces the weight of the optical cable while ensuring the tensile strength.

• The optical cable is compact, lightweight and easy to lay.

Performance:

• Suitable for inter-office communication, agricultural telephone, local telephone relay, CATV and computer network transmission systems.

• Minimum allowable bending radius: static 10 times the cable diameter, dynamic 20 times the cable diameter.

• Working temperature: -40～+70℃.

GYTS

Technical features:

• Number of fiber cores: 2 to 96 cores.

• Low loss, low dispersion.

• Reasonable design and precise control of excess length make the optical cable have excellent mechanical and environmental performance.

• Steel wire armor and steel tape armor make the optical cable have better bending resistance and lateral pressure resistance, and can also resist gunshots and rat bites.

• Small structure, light weight, easy to lay.

• The sheath can be produced with low-smoke halogen-free flame retardant material (the model is GYXTZS at this time).

Performance:

• Suitable for inter-office communication, agricultural telephone, local telephone relay, CATV and computer network transmission systems.

• Minimum allowable bending radius: static 10 times the cable diameter, dynamic 20 times the cable diameter.

• Working temperature: -40～+70℃.
